If you’re a beginner and want to Discover more about how to install wireless security camera system at home with your hand and without wasting money and time on installation services then you’re in the right place. In this simple blog post, we’ll cover everything you need to get your wireless camera system at your home

Security cameras are not a new invention in our world. It has been there for a long time but it’s only now that we realize how important it is.

Nowadays, the number of burglary and theft crimes rise to unbelievable levels, which means not everyone is safe as before.

For home, business, and offices you need to have a wired, or wireless security system to keep monitoring and protecting your property and loved ones.

Wired and wireless surveillance systems have a lot of differences. But in general, wireless devices are easier to install than wired ones and suitable for beginners.

So, in this blog post, we dive into how to install wireless security system at home as it is considered one of the most efficient and cost-effective ways to make sure that your family is safe and secure.

Are wireless security cameras easy to install?

If you are in the industry of security cameras and surveillance devices you may deal with wired analog CCTV cameras, coaxial cables, and DVR (Digital Video Recorder) and see how difficult the installation process of this system is.

On the other hand, we and many homeowners and customers agree that wireless security cameras are easier to install than wired cameras as you don’t have to run cables and unnecessary wires between the camera and the video recorder device.

Plus, the power connection of wireless cam is also easy as it’s powered by a DC power adapter or by a battery.

Can I install my own security cameras?

The answer is Yes, you can install your own wired or wireless security cameras by yourself and you can go far and install wireless security camera system at home without needing help from anyone.

You just need to follow the installation steps in the correct sequence. First, find a good location, then mount the cam, third run camera wires, and the last is to link the camera with your phone.

You can do more or fewer steps depending on many factors such as how large your system is? And the number of cameras? The distance between the system devices? And the availability of a power source near the camera.

If you interested Discover The Best Security Cameras for Bedroom

How to Install Wireless Security Camera System? And What are the tools required for the installation process?

Before we start at how to install wireless security camera system at home you need to

  • Set a plan for your home and where you want to place the camera.
  • Prepare the wires, cables, and where they will pass.
  • Ensure that the tools that you’ll use are ready and without any damage.

If it’s the first time you install a surveillance system and don’t know what are the suitable tools to complete the process? Here are the best tools

Tools Required for Installing Wireless Security Camera System at Home

Wireless security camera systems have two ways to be connected to the NVR (Network Video Recorder).

The first one is by using an Ethernet cable, and the second is through wifi antennas. But in general, the tools for both types are the same such as

  1. Laddar.
  2. Spade Bit.
  3. Screw Bit.
  4. Electric Screwdriver.
  5. Pencil.
  6. Mounting Template.
  7. Electric drill.
  8. Fish tape.
  9. Wire detector.
  10. Electrical Tape.
  11. Hammer.
  12. Hard drive (if it’s not included in the NVR).

These are the most common tools you will need before you start to install wireless security camera system at home.

Note: You may need some additional tools or fewer than the listed above tools but all will depend on your situation.

The installation Steps

If you are installing a security camera system for the first time, you may find it confusing. But don’t worry! By following the step-by-step guide below you will do it professionally.

Step1- Find The Best Available Location

Carefully, when you decide to install wireless security camera system at home with your hand,  you need to find the best available location for the camera.

Choosing a good location for a camera will help you cover and protect your property, and monitor everything happening in your home.

Wherever, inside or outside the home, you should keep the camera at a good spot from which you can see who comes in and out from your area.

Also, you need to keep it high and away from people’s sight to make it hard to reach and protect it from anyone who wants to damage it like intruders, and thieves.

The last thing in the camera placement part is you should make the camera view clear of any obstacle that may affect cam performance such as trees, tall fences, birdhouses, and more.

Note: after you finish selecting the best location for mounting the camera, look at the available power sources that exist near the camera. If there isn’t any power outlet, you can change the camera location or purchase an extension cord.

Step2- Put Mounting Template and Drill Holes

Once you complete the first process, then it’s time to bring your tools and go for the hard step of the installation process which is drilling holes for camera screws, and cables.

First, Pick the ladder you have and put it on the selected camera location.

Second, take the mounting template from the camera package and put it in the camera position.

Third, Put the screw bits on the electric drill to start to drill holes for camera screws. (If you install the cameras on strong material such as concrete you need to install anchors).

Forth, Remove the screw bit and set the spade bit on the drill to make a hole for the cam main cables (power and signal cable).

Fifth, after you drill the big hole for wires, pass the cables through it.

Now, you are finishing one of the hardest steps in the installation process that a lot of people hate to do.

Step3- Fix the Wireless Security Camera

The next step in how to install wireless security camera system at home is to fix the camera at its spot.

Take the screw drive that you buy and fix the screws of the camera one by one, and after you finish adjust the camera angle and direct it to the targeted area.

If you decide to make the connection between the camera and the receiver is wirelessly, then the final thing to do with the camera is to install the camera antenna provided in the device box.

On the other hand, if you want to make the wireless cameras of the system connected to the NVR by cat5 ethernet cables, then you need to bring the fish tape.

First, connect the Ethernet cable first end to the RG45 port of the camera. After that, hook the second end of the network cable to the fish tape.

Second, Pull the fish tape until you see the cable appear from the hole, then remove it from the tape and connect it to one of the NVR ports.

Third, Repeat the previous step with each camera of your system to complete the whole installation process of the system.

Here you’re done with the hardest steps of installing a wireless camera at home, and the other steps are easy to do.

Step4- Turn on the NVR

Everything is connected, and cameras are fixed. The next thing is to turn on the NVR and set the configuration for the features of the system such as motion recording, remote viewing, and storage.

But, before you start doing anything. Check and see if your NVR device has a built-in hard drive or not? If Yes you can go ahead and turn it on, if No then you need to install the hard drive. Just

1- With the screwdriver, unscrew the NVR back and side screws and then remove the top part.

2- Put your hard drive inside the video recorder, and connect it with the connections provided.

3- Fix the hard drive by turning the NVR on its back and holding the hard, and then start to fix the screws.

Now you’re done with your NVR and cameras, and they are ready to start and record and save videos due to the hard drive you installed.

The last thing with NVR is to bring the plug-in adapter of the NVR connect it to the power outlet and then switch the on/off button.

Step5- Hook up the HDMI cable to The Screen.

As we know the HDMI cable is used to connect the camera to the TV. So, To start the setup of the wireless system you need to hook the HDMI cable that is included with the system to your TV screen.

First, Take the cable and connect one end with the back of the NVR and the second with the HDMI port in the monitoring screen.

Second, Change the Input source of the TV to the HDMI channel to view the NVR setting page.

Third, Once you connect everything cameras and NVR are turned on. The cameras will appear on the screen.

Note: If you have a pre-paired wireless camera with NVR, you will see the connection status on each camera section, and sometimes it shows “OFFLINE” until you link the NVR with the modem router.

However, if you are using a network cable to link between cameras and the video recorder make sure that all cameras are connected correctly before going to the next step.

Step6- Connect the NVR to WiFi Router

As we know, these types of cameras have two and sometimes three wires. One for power, the second for the signal which is RJ 45, and the third one for reset.

You may ask Why Should I Connect NVR to a WiFi Router?

Well, to provide full protection security cameras use a feature called Remote Viewing and this advantage allows you to check your home or know what’s going on while you are away.

But, unfortunately, this feature will not work if you don’t have a network connection. So this is the main reason why we connect the NVR to the wifi router.

So, once you connect the Ethernet cable to the LAN port of the network router. The connection status in each camera will be changed to “ONLINE”.

Note: There will be a Cloud ID or Unique ID for every cam that will be used in the next step.

Now, we are reaching the final step of how to install wireless security camera system at home.

After you connect the wireless cameras to the power source and turn them on, you need to link all the devices in one place to make it easy to control the whole system.

For this, every security camera brand in the market has its own mobile app that’s available for both Android and iPhone mobiles.

To download the mobile application for the cameras follow the below steps:

1- Click on the menu in the NVR screen and choose the “Setup the Wizard” option.

2- A new window will open on the screen and there are 3 QR codes to scan.

3- Scan the QR code according to your mobile model if it’s an Android or IOS phone.

4- Once you finish scanning the code, then you will be directed to the APP page on the store, click on Download, and after that INSTALL.

5- Open the mobile app and it will request you to sign up for an account, create an account and save the login details.

6- Click on the “+” sign or “ADD” to add the NVR and the cameras.

7- Scan for the NVR wireless network or scan the last QR code of the NVR and your system will be ready to work.

Now after finishing the below steps your wireless system is connected successfully and you can go for additional settings for cameras such as set time for recording videos, adjusting the level of motion sensor, and testing the 2-way audio if it exists.

For more about how to start to install wireless security camera system at home, watch the next video

Source: Clough Reviews

Summary

At the end of How to install wireless security camera system at home, you are now better informed and can make the best decision when it comes to the installation of your home security cameras.

We also hope that you found this article helpful and that you can now determine which system best fits your needs and budget.
